Paramèt teknik
|
Modèl NO. |
P1.953 |
P2.604 |
P2.976 |
P3.91 |
P4.81 |
|
Pitch Pitch |
1.95mm |
2.6mm |
2.9mm |
3.91mm |
4.81mm |
|
Ki ap dirije kalite |
SMD1415 |
SMD415 |
SMD1921 |
SMD1921 |
SMD2525 |
|
Plate ant modil yo |
Mwens pase oswa egal a 0.1mm |
Mwens pase oswa egal a 0.1mm |
Mwens pase oswa egal a 0.1mm |
Mwens pase oswa egal a 0.1mm |
Mwens pase oswa egal a 0.1mm |
|
Konfigirasyon piksèl |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
|
Gwosè modil (W * H) |
250 * 250mm |
250 * 250mm |
250 * 250mm |
250 * 250mm |
250 * 250mm |
|
Rezolisyon modil (W * H) |
128 * 128mm |
96 * 96mm |
84 * 84mm |
64 * 64mm |
52 * 52mm |
|
Gwosè kabinè (W * H * D) |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
500 * 1000 * 75mm |
|
Rezolisyon kabinè (W * H) |
256 * 512mm |
192 * 384mm |
168 * 336mm |
128 * 256mm |
104 * 208mm |
|
Pwa kabinè |
14.5kg/pc |
14.5kg/pc |
14.5kg/pc |
14.5kg/pc |
14.5kg/pc |
|
Dansite |
262144pwen/m² |
147456 pwen/m² |
112896 pwen/m² |
65400pwen/m² |
43264 pwen/m² |
|
IK |
2153 |
2153 |
2153 |
2153 |
2153 |
|
Eskane |
32S |
32S |
21S |
16S |
13S |
|
Pi bon distans gade |
>1.9m |
>2.6m |
>3m |
>4m |
>5m |
|
Pi bon ang gade |
160 degre / 120 degre |
160 degre / 120 degre |
160 degre / 120 degre |
160 degre / 120 degre |
160 degre / 120 degre |
|
Klète |
5500-6000cd/m² |
5500-6000cd/m² |
6000-6500cd/m² |
6000-6500cd/m² |
6500-7000cd/m² |
|
Travay vòltaj |
AC:110-240V 50 ~ 60Hz |
AC:110-240V 50 ~ 60Hz |
AC: 110-240 V 50 ~ 60Hz |
AC:110-240V 50 ~ 60Hz |
AC:110-240V 50 ~ 60Hz |
|
Maksimòm pouvwa |
Mwens pase oswa egal a 600W/m² |
Mwens pase oswa egal a 600W/m² |
Mwens pase oswa egal a 600W/m² |
Mwens pase oswa egal a 600W/m² |
Mwens pase oswa egal a 600W/m² |
|
Mwayèn konsomasyon pouvwa |
100W/m² |
200W/m² |
200W/m² |
200W/m² |
200W/m² |
|
~300W / m² |
~300W / m² |
~300W / m² |
~300W / m² |
~300W / m² |
|
|
Ogmantasyon tanperati ekran (eta k ap kouri) |
Mwens pase oswa egal a 5 degre |
Mwens pase oswa egal a 5 degre |
Mwens pase oswa egal a 5 degre |
Mwens pase oswa egal a 5 degre |
Mwens pase oswa egal a 5 degre |
|
Operasyon Tanperati Anviwònman / degre |
-10 degre ~60 degre |
-10 degre ~60 degre |
-10 degre ~60 degre |
-10 degre ~60 degre |
-10 degre ~60 degre |
|
Tanperati Fonksyònman |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
|
Pa gen kondansasyon |
Pa gen kondansasyon |
Pa gen kondansasyon |
Pa gen kondansasyon |
Pa gen kondansasyon |
|
|
Tanperati koulè ekran an |
2000K~9500K |
2000K~9500K |
2000K~9500K |
6500K~9500K |
7000K~10000K |
|
Metòd kondwi |
1/32 eskanè |
1/32 eskanè |
1/32 eskanè |
1/16 eskanè |
1/16 eskanè |
|
Echèl gri |
16 bit |
16 bit |
16 bit |
16 bit |
16 bit |
|
Rafrechi frekans |
Pi gran pase oswa egal a 3840Hz |
Pi gran pase oswa egal a 3840Hz |
Pi gran pase oswa egal a 3840Hz |
Pi gran pase oswa egal a 3840Hz |
Pi gran pase oswa egal a 3840Hz |
|
IP klas |
Devan: IP68 |
Devan: IP68 |
Devan: IP68 |
Devan: IP68 |
Devan: IP68 |
|
Retounen: IP66 |
Retounen: IP66 |
Retounen: IP66 |
Retounen: IP66 |
Retounen: IP66 |
|
|
Tan travay kontinyèl |
Pi gran pase oswa egal a 7×24hrs |
Pi gran pase oswa egal a 7×24hrs |
Pi gran pase oswa egal a 7×24hrs |
Pi gran pase oswa egal a 7×24hrs |
Pi gran pase oswa egal a 7×24hrs |
|
Pou tout lavi |
100,000èdtan |
100,000èdtan |
100,000èdtan |
100,000èdtan |
100,000èdtan |
|
Metòd enstalasyon |
Retounen Enstalasyon ankadreman / Levage / Enstalasyon Arc Inner |
||||
|
Koreksyon piksèl |
Ekipe ak pwen pa pwen klète ak koreksyon chromaticity |
||||
|
Mòd kontwòl |
Kontwòl senkronizasyon |
||||
|
Kontwòl distans |
Super senk doub rezo kab, plis pase 100 mèt lè l sèvi avèk transmisyon fib optik |
||||
|
Koòdone lojisyèl |
Windows XP /7/8/10 IOS |
||||
|
Antre siyal |
HDMI, DVI, VGA, USB, LAN (koòdone ekstansib) |
||||
|
Materyèl kabinè |
Ki enpèmeyab Die-casting aliminyòm |
||||
|
Pouvwa Con |
Neut rick Power Connector ak kab |
||||
|
Etè Con |
Neut rick Koneksyon pouvwa ak kab |
||||
|
Metòd antretyen |
Sèvis doub, Antretyen devan ak sèvis dèyè |
||||
|
Tan garanti |
3 ane garanti tan ak sipò teknik gratis pou tout lavi |
||||
Karakteristik
1.Thin ak limyè bwat konsepsyon sove depans anbake
2.Hard konsepsyon koneksyon, fasil enstale ak retire
3.Both antretyen devan ak dèyè yo posib, gwosè kabinè 500mm a 500x1000mm ki disponib.
4.Indoor ekspozisyon ekran konsepsyon, segondè klète, gwo pousantaj rafrechisman, koulè klè
5.Nova sistèm sipò, operasyon senp ak pratik
6.Pwodwi a sipòte personnalisation ak etikèt yo ka Customized
7. anbalaj ka vòl pou transpò pratik ak manyen
Objektif nou se vin pi gwo founisè Lachin nan solisyon ekran ki ap dirije. Nou rasanble yon gwoup pou travay ansanm ak konsantre sou avansman teknoloji ki ap dirije pandan y ap pran tandans mache an kont. Nou konsidere tou ide dènye kri pou amelyore ekran ki ap dirije.
Objektif nou se amelyore teknoloji bon jan kalite vizyèl, pèfòmans ekran ki ap dirije, ak eksperyans itilizatè pandan y ap ofri ekspozisyon LED bon jan kalite, pri-efikas pou yon seri de itilizasyon, ki gen ladan piblisite, enfòmasyon pwodwi, pwogram evènman, ak amizman.
